Install USB modem - Vodafone K4203/Windows 7

Step 1 of 10

Insert your SIM

Turn the front of your USB modem towards you.
Slide the cover upwards and remove it.

Step 2 of 10

Insert your SIM

Turn your SIM as illustrated in the SIM holder.

Step 3 of 10

Insert your SIM

Slide your SIM into the holder.

Step 4 of 10

Insert your SIM

Place the cover on your USB modem with a small opening at the bottom and slide the cover downwards.

Vodafone K4203/Windows 7
Step 5 of 10

Connect your USB modem and your computer

Connect your USB modem to your computer's USB port.

Step 6 of 10

Install USB modem

If the installation doesn't start automatically:
Click the Windows icon.

Step 7 of 10

Install USB modem

Click Computer.

Step 8 of 10

Install USB modem

Click VMB Lite.

Step 9 of 10

Install USB modem

Double-click setup_vmb_lite.
Follow the instructions on the screen to install your USB modem.

Step 10 of 10

Install USB modem

Highlight the field below "Please enter your PIN code before continuing".
Key in your PIN and press Enter.

1. Insert your SIM

Turn the front of your USB modem towards you.
Slide the cover upwards and remove it.
Turn your SIM as illustrated in the SIM holder.
Slide your SIM into the holder.
Place the cover on your USB modem with a small opening at the bottom and slide the cover downwards.

2. Connect your USB modem and your computer

Connect your USB modem to your computer's USB port.
Vodafone K4203/Windows 7

3. Install USB modem

If the installation doesn't start automatically:
Click the Windows icon.
Click Computer.
Click VMB Lite.
Double-click setup_vmb_lite.
Follow the instructions on the screen to install your USB modem.
Highlight the field below "Please enter your PIN code before continuing".
Key in your PIN and press Enter.
